Wireless Deadman Bundle

P/N
3A466B

Variable Pricing

In stock

Kar-Tech wireless Deadman kits are safe, smart, and affordable. With our wireless mesh control, you can safely stop up to eight pieces of equipment in real-time with one wireless Deadman transmitter. It is designed to meet the rigorous requirements for Safety Integrity Level (SIL) 2 based on the IEC61508  standard.

Our wireless Deadman system starts with a receiver with two independent solid-state sourcing outputs rated for 5A each - one which turns ON when Deadman switch is pressed and turns OFF as soon as switch is released. The second output turns ON when Deadman switch is pressed after receiver power up and turns OFF when switch is released but requires recycling receiver power after to clear the output.  And because the name of the game is safety - there are redundancies at both the transmitter and receiver. The transmitter uses two normally open switch contacts in series for redundant protection, and the receiver uses the third output to activate the two main outputs - if it notices a short circuit, it will engage an E-Stop condition.

Only one transmitter is needed to command up to 8 receivers, so that a single operator can safely stop up to eight pieces of equipment. It's important to note: these are all two-way radios in a mesh configuration so that the operator has real-time indication of machine issues and radio link status!

Customize Wireless Deadman Bundle

Wireless Deadman - Pocket-Clipped

3A466BA

Wireless pocket-clipped Deadman remote with top-mount sealed switch and bottom mount Micro-USB connector for recharging its lithium-polymer batteries

Your System

DC Wireless E-Stop Receiver

3A4663C

This weatherproof wireless radio receiver is housed in a urethane-encapsulated enclosure and provides up to 600' of wireless range. It has two E-Stop outputs, removable antenna with an RP-SMA connector at the receiver, and runs on a supply voltage of between 9 - 30VDC, suitable for 12V or 24V applications.

Your System

Industrial AC Wireless E-Stop Receiver

3A466GB

This weatherproof wireless radio receiver is housed in a urethane-encapsulated enclosure and provides up to 600' of wireless range. It has two E-Stop outputs, removable antenna with an RP-SMA connector at the receiver, and runs on a supply voltage of between 9 - 30VDC supplied with universal AC to DC converter and suitable for AC applications.

Your System

Micro USB Wall Charger

Your System

Micro USB Car Charger

Your System

* Required Fields

Your Customization
Wireless Deadman Bundle
Wireless Deadman Bundle

In stock

$19.99

-
+
Summary
